Advance +

Fireproof with the REI criterion

Advance +

This unit, Advance +, meets fire performance criteria REI(w) 60.
Especially in multi-storey buildings, fire resistance of the lower storey is of vital importance: the whole structure must not collapse.
The Advance + has a unique supporting structure.

The effects after 60 minutes on load bearing capacity (R), flame density (E) and insulation (I) are minimal, the protection is maximum.

Het Advance + range consists of 3 unit ranges

  • Standaard units: 8 configurations that represent the perfect base for your building
  • Sanitary units: if you need a shower, washing area or toilet, there are 7 configurations to choose from
  • Staircase: if you need a 2-storey building, there are 2 covered staircases to choose from
  • Standard units
  • Sanitary facilities
  • Staircase
Advance Plus

These units are available with 4, 3, or 2 outer walls
In addition, we have configurations available that have an inner wall to create a hallway that creates two separate spaces.

The standard size is 18m² (approximately 6 x 3 m).

All our units are fitted with:

  • 1 double window with shutters
  • Electricity cables hidden away in the wall and ceiling.
  • Electrical heating
  • Marmoleum floor covering
  • In addition, they all meet the REI criteria

 If you want additional security, data points, etc., please consider our 360° Services.

FL140RF - Enclosed unit

Standard version of 18m² with:

  • 4 side walls
  • 1 end door on the front side
  • 1 double window at the rear





FL150RF -  Semi-open unit with 3 outer walls and 1 open left wall

Standard version of 18m² with:

  • 3 side walls
  • 1 open side wall on the left side
  • 1 double window at the rear





FL160RF - Open unit with 2 outer walls and 2 open side walls

Standard version of 18m² with:

  • 2 side walls (on the front and back side)
  • 2 open side walls on the left and right side
  • 1 double window at the rear





    FL170RF - Semi-open unit with 3 outer walls and 1 open right wall

    Standard version of 18m² with:

    • 3 side walls
    • 1 open side wall on the right side
    • 1 double window at the rear





    FL180RF - Enclosed unit with 4 outer walls and hallway

    Standard version of 18m² with:

    • 4 side walls
    • hallway with integration of 1 inner door
    • 1 double window at the rear





    FL190RF -  Semi-open unit with 3 outer walls and hallway

    Standard version of 18m² with:

    • 3 side walls (open on the left side)
    • hallway with integration of 1 inner door
    • 1 double window at the rear





    FL200RF -  Open unit with 2 outer walls and 1 inner wall

    Standard version of 18m² with:

    • 2 outer walls
    • 2 open side walls
    • hallway with integration of 1 inner door
    • 1 double window at the rear





    FL210RF -  Semi-open unit with 3 outer walls and hallway

    Standard version of 18m² with:

    • 3 side walls (open on the right side)
    • hallway with integration of 1 inner door
    • 1 double window at the rear


    Advance Flash sanitair

    If you require a toilet or shower room as part of your project, you can choose from 7 sanitary configurations from the Advance REI 60 range. The standard size of these units is 18m².

    Choose from the configurations below, with showers, toilets, urinals and wash throughs.



    FL233RF - Enclosed unit with 4 showers, 2 washbasins and heat boiler

    • 4 outer walls
    • 1 double window at the rear
    • 4 seperate showers
    • 2 washbasins
    • 1 heat boiler





    FL240RF - Enclosed unit with 5 seperate toilets and washbasins

    • 4 outer walls
    • hallway with integration of 1 inner door
    • 4 seperate toilets
    • 2 washbasins





    FL245RF - Enclosed unit with 2 seperate toilets, 3 urinals and wash throughs

    • 4 outer walls
    • hallway with integration of 1 inner door
    • 2 seperate toilets
    • 3 urinals
    • 3 wash throughs





    FL146RF - Enclosed unit with wash throughs

    • 4 outer walls
    • 1 inner wall for hallway with integration of 1 inner door
    • 4 wash throughs
    • 1 heat boiler





    FL255RF - Enclosed unit with seperate toilets, urinals and washbasins

    • 4 outer walls
    • hallway with integration of 2 inner doors
    • ladies' room with washbasin
    • men's room:
      -- 2 seperate toilets
      -- 3 urinals
      -- 1 washbasin





    FL265RF - Enclosed unit with 2 seperate restrooms

    • 4 outer walls
    • open space with 2 inner doors
    • 2 seperate restrooms with:
      -- seperate washbasin
      -- seperate toilet





    FL274 - Enclosed unit with seperate toilet and shower area

    • 4 outer walls
    • hallway with integration of 1 inner door
    • open space with 2 inner doors
    • 2 seperate spaces with shower or toilet
      -- space 1: toilet with seperate washbasin
      -- space 2: shower with dressing corner and washbasin


    Advance Flash trappenhal

    If you need a 2-storey building, you can choose from 2 units with built-in stairs.

    Both units are 18m² in size and feature a double exterior door.

    FL648RF - Enclosed unit with single staircase

    • 4 outer walls
    • double door, opening outwards
    • single staircase to the top



      FL649RF - Enclosed unit with double staircase

      • 4 outer walls
      • double inward-swinging door
      • double staircase with landings
